ASUS ExpertWiFi EBP15 5-Port GbE Smart Managed PoE+Switch / 90IG08D0-MO3B00
כללי
-
סוג מוצר
מתג
-
יצרן
Asus
-
דגם
ExpertWiFi EBP15
-
צבע
White
אחריות
-
תקופת האחריות
שלוש שנים
סקירה כללית
Port Attributes
Five 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
AUTO Negotiation/AUTO MDI/MDIX
Standard
IEEE 802.1p
IEEE 802.1q
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3i
IEEE 802.3u
IEEE 802.3x
IPv4
IEEE 802.1q
IEEE 802.3ab
IEEE 802.3af
IEEE 802.3at
IEEE 802.3i
IEEE 802.3u
IEEE 802.3x
IPv4
PoE Budget
60 watts
Performance
MAC Address : Up to 8 K
Buffer Memory : 4 Mbits
Switching Capacity : 10Gbps
Packet Forwarding Rate : 7.44Mpps
Jumbo Frame : 15KB
Buffer Memory : 4 Mbits
Switching Capacity : 10Gbps
Packet Forwarding Rate : 7.44Mpps
Jumbo Frame : 15KB
LED Indicator
System power ON/OFF
PoE Alert
Link, Speed, activity, and PoE indicators per port built into each RJ-45 port
PoE Alert
Link, Speed, activity, and PoE indicators per port built into each RJ-45 port
Power Supply
AC input: 100V~240V (50~60 Hz)
DC output: 54V with 1.25A
DC output: 54V with 1.25A
PoE Ports
Standard: 802.3 af/at compliant
PoE Ports: Port 1 – Port 4
Per Port Max: 30W
PoE Ports: Port 1 – Port 4
Per Port Max: 30W
Management
Quality of Service
IGMP Snooping
Port Mirroring
Loop Detection/Prevention
Web-based GUI
ExpertWiFi APP (with ExpertWiFi products only)
IGMP Snooping
Port Mirroring
Loop Detection/Prevention
Web-based GUI
ExpertWiFi APP (with ExpertWiFi products only)
Environmental
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -20℃~70℃ (-4℉~158℉)
Operating Humidity: 10%~95%RH non-condensing
Storage Humidity: 5%~95%RH non-condensing
Storage Temperature: -20℃~70℃ (-4℉~158℉)
Operating Humidity: 10%~95%RH non-condensing
Storage Humidity: 5%~95%RH non-condensing
Product Category
PoE+ Switch
Software Features
ExpertWiFi AiMesh Mode (with ExpertWiFi router only): centrally control the connected devices via ASUSWRT/ExpertWiFi app
Standalone Mode: IGMP Snooping, VLAN, Loop Detection/Prevention, Port Mirroring, Port-based QoS, 802.1p CoS, Firmware Update, PoE priority setting, PoE status
Standalone Mode: IGMP Snooping, VLAN, Loop Detection/Prevention, Port Mirroring, Port-based QoS, 802.1p CoS, Firmware Update, PoE priority setting, PoE status
Security
SSL/TLS
Package Content
ExpertWiFi EBP15
RJ45 Ethernet Cable
Power Adapter
Quick Start Guide
Warranty Card
RJ45 Ethernet Cable
Power Adapter
Quick Start Guide
Warranty Card
Product Weight (g)
248g
